The size of the header pins should correspond to the same of the header holes, otherwise, the connection is not tight enough and easy to loosen. It can be cut according to different needle number requirements to achieve the actual number of needles used. Choose the header according to the required number of pins and the pin spacing, and insert it directly into the breadboard to connect or form a connector with the header to achieve the purpose of connection.

Key Features:

• 2.54mm pitch right-angle male connector for PCBs.
• Ideal for extending microcontroller and IC pins.
• Compatible with LCD, OLED, or VFD modules.
• Secure connection with matching header pin sizes.
• Versatile applications including PCB prototypes and breadboards.
• Easy through-hole mounting.
• Durable plastic construction for DC power up to 3A.

Applications:

• Used to connect the PCB prototype and the breadboard
• The docking of the small board and the breadboard
• As a through stacking head on the PCB

  Package Includes:

  1 x 40x1 Male Berg (90 Degree)
