It is NPN dc6-36v inductive proximity sensor detection switch. Features: proximity switches, also known as non-contact proximity switch, is the ideal electronic switch sensor. When the metal detecting near-proximity switch sensing area. Switches can be non-contact, no pressure, no spark, quickly issued electrical command. Accurately reflect the position and stroke movement mechanism. Positioning accuracy, operating frequency, service life. Easy to install and suitable for harsh environments the ability to adjust. General mechanical limit switch can not be compared. Specifications: model: lj12a3-4-z / by. Operating voltage: dc 6-36v range within universal. Output type: pnp normally open three-line. Detection object: metal objects. Detection distance: 4 mm. Output current: 300 ma. Response frequency: 0. 5Kh. Working temperature: temperature range -30 degree - = 60 degree, + 23 degree, within+ (-) 15 percent detection distance. Temperature range: -25? to + 60? within + (-) 10 percent detection distance. Dimensions: 12 mm screw diameter. Cable length: about 115 cm. Material: metal and plastic.

Package includes: 1 x  Metal Inductive Proximity sensor detection switch.
