Description
The DC Motor Speed Controller allows controlling direction of a DC motor using a Pulse-Width-Modulated (PWM) DC voltage with a Duty Cycle fully adjustable from 10%-100%. The motor speed controller can provide a continuous current of 8A to your DC motor or other DC load. The circuit also includes a 10A fuse, with the reverse connection of power supply and control voltage over-voltage protection function.
Note:
This can NOT be used to the BRUSHLESS motor. The controller is NOT reverse-polarity protected and will be damaged if it connects the supply voltage with the wrong polarity.
Features:-
Control the speed of a DC motor with this controller.
High efficiency, high torque, low heat generating.
With reverse polarity protection, high current protection.
Control voltage over-voltage protection function
The overload and short circuit protecting current is 10A
Working Voltage: DC 12V DC 40V.
Control Power:0.01 400W.
Static Current:0.02 A ( Standby ).
PWM Duty Cycle:10% -100%.
Specifications:-
Input supply voltage DC 12V-40V
The maximum output power 400W
The maximum continuous output current 8A
Static Current 0.02 A ( Standby )
PWM frequency 13kHz
Material Plastic, metal
Duty Cycle adjustable 10%-100%
The operation environment temperature:-20-40
Dimension(cm) 6*5.5*2.8
Net weight 69g
Package Includes:
1 x 12V-40V10A DC Motor PWM Speed Control Switch Governor
