This is a 12V Electronic Cabinet/Door Lock. You can lock and unlock Cabinets/Doors using a 12V power supply. When the coil is energized, the slug is pulled into the center of the coil and the cabinet/door is unlocked. When 12V power is removed, an internal spring pushes the slug out and the cabinet/door is locked again. This lock is great for DIY and Hobby Projects - Home Automation, Smart and Automatic Doors, Cabinets and Windows, etc This means that when activated with up to 12VDC, the solenoid moves and when the voltage is removed it springs back to the original position, which is quite handy. This one even has nice mounting holes, it's a great all-purpose solenoid. You will need a power transistor and a diode to drive a 12V lock from an Arduino or any other microcontroller. You can also use our relay boards to control the lock from an Arduino. You will need a fairly good power supply to drive a lock, as many currents will rush into the lock to charge up the electro-magnet, so don't try to power it with a 9V battery.

Specifications:

• Operation Voltage:12VDC ±10%(you can use 9-14 DC volts, but lower voltage results in weaker/slower operation)
• Current: 500mA
• Power: approx. 6W
• Operation Mode:    Fail Locked
• Length of tongue:6mm
• Unlock time: 1 second
• Maximum power on time: Less than 5 seconds
• Working Temperature:-25ºC ~ +80ºC
• Dimension(L*W*H):28mm*27mm*19mm
• Weight    130g

Features:

• Surface-mounted compact electric lock
• Reversible bolt for up and down
• Superior heavy-duty metal construction
• Suitable for Lockers, furniture, mailboxes and drawers, etc.

Applications:

• They are widely used in automation projects, electronic safes, etc.

Package Includes: 1 x 12V DC Mini Electric Solenoid Lock

Note: Take care of polarity while making the connection without connector (i.e. Red wire should be connected to the positive and Black wire to negative.)
